Focus Jam2 8.7 eMTB 2023
Focus Jam2 8.7 eMTB 2023
-
The Focus Jam2 8.7 eMTB is best price carbon model in the new 2023 all-mountain carbon Jam2 range. Focus have upped the ante with some big upgrades this year including 4-bar linkage and a new frame to accommodate the Smart System Bosch CX motor and 750Wh battery. The Jam2 8.7 delivers all of the major upgrades and you still get 160mm travel upfront with the DVO Diamond E3 Fork, 4-piston SRAM Guide T hydraulics, and Minion DHF/Rs.
-
- Drive System: Bosch Smart System
- Motor: Bosch Performance CX, 85Nm of torque
- Battery: Bosch Lithium-ion 625Wh (powertube)
- Comfort: Front suspension, rear suspension, ergonomic saddle, plus size tires
- Accessories: Mounts to add a rear rack, mudguards, lights if required
- Brand: Focus
Details
Best price carbon all-mountain eMTB. The Focus Jam2 8.7 eMTB is best price carbon model in the new 2023 all-mountain Jam2 range.
Focus have upped the ante with some big upgrades this year including 4-bar linkage and a new frame to accommodate the Smart System Bosch CX motor and 750Wh battery. The Jam2 8.7 delivers all of the major upgrades and you still get 160mm travel upfront with the DVO Diamond E3 Fork, 4-piston SRAM Guide T hydraulics, 12-speed SRAM gearing and Minion DHF/Rs.
Bosch Smart System. You get the Bosch 750Wh powertube battery as standard, which means more laps, bigger days, or more time in Turbo. Download the Bosch eBike flow app to unlock customisable rider modes, fitness and performance data, as well as security features. Add the Bosch eBike Alarm and Connect Module to add a integrated 100dB alarm and GPS tracking to your pride and joy.
Ground Up Frame Redesign.To accomodate the new 750Wh Bosch Smart System power tube battery Focus rotated the Bosch Race CX motor to allow the battery to sit low in the down tube and help keep the weight low down in the bike.
The battery is still removable however to increase frame stiffness and reduce weight the opening for battery removal is at the bottom of the downtube, protected by a sturdy skid plate.
The Jam2 8.7 eMTB has a full carbon frame with alloy chain stay and rocks a stunning two-tone paint finish with a choice of two frame colours. The Jam2 bikes also now have a fully active 4-bar rear suspension linkage which is paired with a Fox Float DPS rear shock on the 8.8.
Slack or slacker? For more aggressive trails you can slacken the head angle from 65.5 to 64.5 using the rotatable headset cups. This matches the Sam2 6.9 in its least slack setting.
Contact us to preorder. See the Jam2 8.8 if you prefer Fox forks.
System | Bosch Smart System, 250W mid-drive |
---|---|
Motor | Bosch Performance CX, 85Nm |
Battery |
Bosch PowerTube 750Wh
|
Charger | Bosch 4A |
Display | Bosch System Controller + Mini Remote |
Frame |
Carbon front triangle, aluminium rear triangle, 150 mm F.O.L.D. GEN2 kinematics, 148x12 mm thru axle, internal cable routing, post mount 203 mm |
---|---|
Sizes | S 39 M 42 L 44 XL 46 |
Colours | Raw Carbon / Moonstone; Raw Carbon / Bluegreen |
Fork |
DVO Diamond E3, 110x15 mm, 44 mm rake |
Travel | 160mm |
Rear Suspension | Rock Shox Deluxe Select, 210/55 mm, Hardware: 25.0 x 8.0 mm, no Bushing |
Wheel Size | 29" |
Wheelset | DT Swiss H1900, 30-622, 15x110 mm / 12x148 mm |
Tyres |
Maxxis Minion DHF, 2.6 EXO+ / Maxxis Minion DHRII, 2,6 EXO+
|
Gearing |
SRAM SX Eagle, 12-speed |
Sprocket |
SRAM PG-1230 NX Eagle, 12-speed |
Chain |
SRAM SX Eagle, 12-speed
|
Brakes |
SRAM GUIDE T hydraulic |
Handlebar |
Aluminium, 800 mm, rise: 30 mm, backsweep: 9° |
Stem | FOCUS C.I.S. integrated, 50 mm, 0°, 35 mm, aluminium |
Saddle |
Selle Royal Groove
|
Seatpost | Post Moderne dropper post PM-214, 34.9 mm |
Weight |
23.7kg inc battery |
Carry Capacity | 150kg inc rider |
Geometry | See Focus website |
Lights | No - mounts provided |
---|---|
Lock | No |
Carrier Rack | No - mounts provided |
Mudguards |
No - mounts provided
|
Kickstand | No |
