Orbea Kemen Mid 10 EBike - Used (M)

Full Specification
Orbea Kemen Mid 10 EBike - Used (M)
Bike Overview

Orbea have taken a different approach to the traditional usually-heavy multipurpose urban ebike. Their aim was to build a robust and comfortable ebike that was as light and slim as possible, and was also easy to ride without power if necessary. The result is the Orbea Kemen. A bike that is beautiful and clean to look at and has the capability to be a workhorse as well as a fast and fun urban runaround.

Orbea Kemen Mid 10 E-Bike

To create the sleek look, light weight, rideability and robustness needed for the Kemen ebike Orbea designed a brand new frame that can accommodate the top equipment for performance and lighter weight. The Kemen has allterrain geometry and a strong hydroformed aluminium frame with high-polished welds that not only looks beautiful but is extra-strong and comfortable to ride.

Orbea use the Shimano EP8 motor which is not only very strong with 85Nm but is also compact, lightweight and offers the least resistance of any motor when pedalling without power. They achieve their sleek clean lines by routing all cabling through the frame and the frame also houses the large 540Wh high-density battery. If up to 5 hours of riding isn't enough there is also the option to mount a 252Wh range extender.

The Orbea Kemen models have slightly narrower 2.25" slicker tires and the Kemen 10 is equipped with top-of-the-range componentry. It uses Shimano XT 11-speed gears with linkglide, a Fox 34 Float AWL fork with 100 mm travel and a lighting system from Lezyne with 1,000 lumens of light for night riding. Also fully compatible with the rear axles used by follow me or tow along baby carriages.

Contact us to order or order online. This Used model is a Medium has <1,000km and is in excellent visual and working condition. Some marks on the rear rack from pannier bags. Sold with EBB Used Approved 6 moths warranty.

Delivery to regional and interstate locations may attract additional charges depending on delivery address. Discount vouchers not applicable whilst on sale.



EBike Technology
System Shimano EP8 mid-drive 250Wh
Motor Shimano EP8, 85Nm
Battery Orbea Internal 540Wh
Range extender: 252Wh
Range Varies. Up to 5 hours
Display Shimano SC-EM800
Remote RS
Charger Orbea Smart Charger (42V-4A)
Bike Specification
Components (See Orbea for further details)
Frame Orbea Kemen Mid Bar, Shimano Steps, Integrated battery, Hydroformed Alloy 6061 series Internal Cable Routing, Boost 148x12
Lifetime warranty
Sizes S: 40, M: 45, L: 48, XL: 53
See here for geometry and size guide
Colours Night Black; Dark Red; Urban Green
Fork Fox 34 Float AWL 100 RAIL QR15x110
Wheel Size 29"
Crankset Shimano Steps EM600
Headset FSA 1-1/2" Integrated Aluminium Cup
Handlebar OC 35mm 20mm Rise 780mm
Stem OC1 35mm interface -6º
Shifters Shimano XT M8130 Link Glide
Brakes Magura MT5 E-STOP Hydraulic Disc Easy Route Connection
Cassette
Shimano CS-LG600 11-50t 11-Speed
Rear Derailleur
Shimano XT M8130 Link Glide SGS Shadow Plus
Chain
Shimano LG500
Chainguide Alloy EP8 36t w/chainguard
Wheels
Orbea OC1 25c Tubeless Ready
Tires Schwalbe G-ONE Allround, 29x2,25, Performance Line RaceGuard, TLE, Reflective
Seatpost
OC Mountail Control MC20, 31.6mm, Dropper
Saddle Selle Royal Vivo 1216 DRN 160x249mm
Pedals VP-537 Black
Weight Approx 22kg
Fitted Accessories
Fitted Accessories
Lights F: Lezyne Super HB STVZO 1000 with Remote, Low Bean 600 Lumens, High Bean 1000 Lumens
R: Lezyne FENDER STVZO Alert Technology 11Lumen
Lock No
Carrier Rack Orbea Kemen oversize Alloy Rear Carrier (Max:18Kg)
Mudguards CURANA Apollo 65mm
Kickstand Ursus Mooi rear adjustable

Orbea have taken a different approach to the traditional usually-heavy multipurpose urban ebike. Their aim was to build a robust and comfortable ebike that was as light and slim as possible, and was also easy to ride without power if necessary. The result is the Orbea Kemen. A bike that is beautiful and clean to look at and has the capability to be a workhorse as well as a fast and fun urban runaround.

Orbea Kemen Mid 10 E-Bike

To create the sleek look, light weight, rideability and robustness needed for the Kemen ebike Orbea designed a brand new frame that can accommodate the top equipment for performance and lighter weight. The Kemen has allterrain geometry and a strong hydroformed aluminium frame with high-polished welds that not only looks beautiful but is extra-strong and comfortable to ride.

Orbea use the Shimano EP8 motor which is not only very strong with 85Nm but is also compact, lightweight and offers the least resistance of any motor when pedalling without power. They achieve their sleek clean lines by routing all cabling through the frame and the frame also houses the large 540Wh high-density battery. If up to 5 hours of riding isn't enough there is also the option to mount a 252Wh range extender.

The Orbea Kemen models have slightly narrower 2.25" slicker tires and the Kemen 10 is equipped with top-of-the-range componentry. It uses Shimano XT 11-speed gears with linkglide, a Fox 34 Float AWL fork with 100 mm travel and a lighting system from Lezyne with 1,000 lumens of light for night riding. Also fully compatible with the rear axles used by follow me or tow along baby carriages.

Contact us to order or order online. This Used model is a Medium has <1,000km and is in excellent visual and working condition. Some marks on the rear rack from pannier bags. Sold with EBB Used Approved 6 moths warranty.

Delivery to regional and interstate locations may attract additional charges depending on delivery address. Discount vouchers not applicable whilst on sale.



System Shimano EP8 mid-drive 250Wh
Motor Shimano EP8, 85Nm
Battery Orbea Internal 540Wh
Range extender: 252Wh
Range Varies. Up to 5 hours
Display Shimano SC-EM800
Remote RS
Charger Orbea Smart Charger (42V-4A)
Components (See Orbea for further details)
Frame Orbea Kemen Mid Bar, Shimano Steps, Integrated battery, Hydroformed Alloy 6061 series Internal Cable Routing, Boost 148x12
Lifetime warranty
Sizes S: 40, M: 45, L: 48, XL: 53
See here for geometry and size guide
Colours Night Black; Dark Red; Urban Green
Fork Fox 34 Float AWL 100 RAIL QR15x110
Wheel Size 29"
Crankset Shimano Steps EM600
Headset FSA 1-1/2" Integrated Aluminium Cup
Handlebar OC 35mm 20mm Rise 780mm
Stem OC1 35mm interface -6º
Shifters Shimano XT M8130 Link Glide
Brakes Magura MT5 E-STOP Hydraulic Disc Easy Route Connection
Cassette
Shimano CS-LG600 11-50t 11-Speed
Rear Derailleur
Shimano XT M8130 Link Glide SGS Shadow Plus
Chain
Shimano LG500
Chainguide Alloy EP8 36t w/chainguard
Wheels
Orbea OC1 25c Tubeless Ready
Tires Schwalbe G-ONE Allround, 29x2,25, Performance Line RaceGuard, TLE, Reflective
Seatpost
OC Mountail Control MC20, 31.6mm, Dropper
Saddle Selle Royal Vivo 1216 DRN 160x249mm
Pedals VP-537 Black
Weight Approx 22kg
Fitted Accessories
Lights F: Lezyne Super HB STVZO 1000 with Remote, Low Bean 600 Lumens, High Bean 1000 Lumens
R: Lezyne FENDER STVZO Alert Technology 11Lumen
Lock No
Carrier Rack Orbea Kemen oversize Alloy Rear Carrier (Max:18Kg)
Mudguards CURANA Apollo 65mm
Kickstand Ursus Mooi rear adjustable
