Tern Quick Haul D8 EBike
Tern Quick Haul D8 EBike
-
The Tern Quick Haul ebike offers commuters and urban dwellers an easy-to-manage city ebike with extra cargo carrying capability. It is a 20" wheel low-step ebike that is shareable amongst riders of varying heights and can carry up to 150kg and with longer rear rack can take 50kg. The Quick Haul D8 version is powered by the smooth Bosch Active Plus motor and comes with 400Wh battery. With a host of accessories to choose from this is a top 'daily ride' option.
-
- Drive System: Bosch Active Line Plus
- Motor: 250W mid-drive, 50Nm of torque
- Battery: Bosch Lithium-ion 400Wh (powerpack)
- Range: Up to 100km
- Comfort: Adjustable handlebars, balloon tires, ergonomic seat and grips
- Accessories: Lights, lock, mudguards, heavy duty rear carrier rack
- Brand: Tern
Details
The Multi-tool of EBikes. The Tern Quick Haul is designed to offer commuters and urban dwellers an easy-to-manage city ebike that has extra cargo carrying capability. With its 150kg carry capacity, 20" wheels, low step frame, height adjustability and lighter weight at 23kg the D8 model is the most economical model in the Tern range.
The Tern Quick Haul D8 is powered by the strong and efficient Bosch Active Line Plus motor with a 400Wh powerpack battery. With 50Nm of torque it makes hills enjoyable with and without cargo, and you can expect up to approx 100km range depending on your your power usage.
The Quick Haul runs on strong 20" wheels and Schwalbe Big Ben balloon tires offers puncture resistance and traction. The 8-speed Shimano gearing system is simple and provides plenty of gears and you have peace of mind with Shimano hydraulic disc brakes in the dry or wet.
The Quick Haul is a very flexible bike in many aspects. The speedlifter handlebars and adjustable seatpost offer flexibility for rider heights from 160-195cm and if you opt for the optional shorter 350mm seatpost it suits riders from 145cm.
With its longer rear rack with 50kg carry capacity the Quick Haul allows you to carry more than your average city ebike and Tern offers an excellent range of accessories for you to configure your Quick Haul for just how you plan to use it too. An incredibly useful 'daily ride'!
If you prefer a more powerful motor see the Tern Quick Haul P9 with Bosch Performance motor (bike reviewed below).
| System | Bosch Active Line Plus |
|---|---|
| Motor | Bosch 250W mid-drive, 50Nm |
| Battery |
Bosch Powerpack 400Wh
|
| Charger | Bosch 2A |
| Display | Bosch Purion |
| Frame | Tern Quick Haul, Patented Design, 6061-AL, EFBE Tri-Test approved: 150 kg |
|---|---|
| Sizes | One size |
| Colours | Silver Blue |
| Fork |
Cargo, steel, EFBE approved: 150 kg
|
| Wheel Size | 20" |
| Tires |
Schwalbe Big Apple, 55-406, puncture protection, Reflex
|
| Rims | Kinetix Comp, for disc |
| Shifting System |
Shimano Altus 1 x 8-sp |
| Cassette | himano 11-34T, 8 spd |
| Chain | KMC for ebike, 8 spd |
| Brakes |
Shimano, hydraulic disc
|
| Handlebar |
Low riser, 31.8, 6061-AL
|
| Stem |
Speedlifter, 150 mm extension, 3D Forged stem, 31.8
|
| Saddle |
Velo Comfort
|
| Seatpost |
31.6 mm, 6061-AL, micro-adjust clamp
|
| Pedals | Urban with non-slip surface |
| Carry Capacity | 150 kg (330.7 lb) incl rider |
| Weight | 22.8kg |
| Lights |
Front: Herrmans, 120 lumens
Rear: Herrmans |
|---|---|
| Lock | n.a |
| Carrier Rack | Atlas Q Rack, UpperDeck Mount System, Vertical Parking, 50 kg capacity |
| Mudguards |
Chromeplastic, stainless hardware
|
| Kickstand |
Pletscher design, rear mount
|
| Accessories | An excellent selection to customise your bike See the Tern website for details |
