Focus Sam2 6.9 eMTB
Focus Sam2 6.9 eMTB
-
The Focus Sam2 6.9 is one of the the top-of-the-range models in the new Sam2 enduro / downhill eMTB range. Focus has moved the game on with the Bosch Smart System drive system and 750Wh battery. "Designed for Down", it also has a completely new frame and suspension setup with fully active 4-bar linkage while retaining the same downhill DNA of the previous model (burley frame, slack head angle 63.5 or 64.5, Fox Float Factory 180mm travel, Fox DH coil shock).
-
- Drive System: Bosch Smart System
- Motor: Bosch Performance CX, 85Nm of torque
- Battery: Bosch Lithium-ion 750Wh (powertube)
- Performance: FOX 38 Float Factory fork, Fox DH Performance coil shock, Shimano Deore XT gears, Magura MT5 brakes
- Brand: Focus
Details
Top Enduro eMTB featuring Fox 38 Factory, Fox DHX Performance Coil, and XT. The Focus Sam2 6.9 is one of the the top-of-the-range models in the new Sam2 enduro / downhill eMTB range.
"Designed for Down", it also has a completely new frame and suspension setup with fully active 4-bar linkage while retaining the same downhill DNA of the previous model (burley frame, slack head angle, 180/170mm).
The Sam2 6.9 runs with FOX 38 Float Factory fork 180mm, Fox DH Performance coil shock 170mm, Shimano Deore XT 12-speed gears, Magura MT5 brakes and DT Swiss wheelset
Bosch Smart System. You get the Bosch 750Wh powertube battery as standard, which means more laps, more downs, bigger grin. Download the Bosch eBike flow app to unlock customisable rider modes, fitness and performance data, as well as security features. Add the Bosch eBike Alarm and Connect Module to add a integrated 100dB alarm and GPS tracking to your pride and joy.
Ground Up Frame Re-design. To accomodate the big 750Wh battery and new Bosch Smart System CX motor Focus have rotated the motor to allow the battery to sit low in the downtube and help keep the weight low down in the bike.
The battery is still removable. However to increase frame stiffness and reduce weight, the opening for battery removal is at the bottom of the downtube, protected by a sturdy skid plate. This means the frame wall thickness can be reduced to deliver the same stiffness at a lower weight than the previous larger cut out dual wall frame design.
Contact us to order or order online. See the Jam2 6.9 if you prefer a fast trail / all-mountain eMTB with Fox Float Factory. (Note video below is Sam2 6.0 version).
Delivery interstate and regionally to certain locations is available and extra charges may apply depending on location. Discount vouchers not applicable whilst on sale.
System | Bosch Smart System, 250W mid-drive |
---|---|
Motor | Bosch Performance CX, 85Nm |
Battery |
Bosch PowerTube 750Wh
|
Charger | Bosch 4A (Smart) |
Display | Bosch LED Remote + Kiox 300 |
Frame |
7005 hydroformed aluminium, 3D forging, 170 mm F.O.L.D. Gen2, 148x12 mm thru axle, internal cable routing, post mount 203 mm |
---|---|
Sizes | S 39 M 42 L 44 XL 46 |
Colours | Light Grey / Moonstone Grey |
Fork | FOX 38 Float Factory 29, Grip 2, E-Bike+, 110x15 mm, 44 mm rake |
Travel | 180mm |
Rear Suspension |
FOX DHX Performance Coil, 230/65 mm, hardware: 20,0 x 8.0 mm |
Wheel Size | 29" |
Wheelset | RaceFace ARC 30 / Novatec hub |
Tyres |
Maxxis Minion DHF, 2.6 EXO+ / Maxxis Minion DHRII, 2,6 EXO+
|
Gearing |
Shimano Deore XT M8100, 12-speed front: 34, rear: 11-51 |
Sprocket | Shimano SLX M7100, 12-speed |
Chain | Shimano SLX CN-M7100, 12-speed |
Brakes | Shimano XT M8120, 4 piston |
Handlebar | RaceFace Chester 35, aluminium, 780 mm, rise: 35 mm, backsweep: 8° |
Stem | FOCUS C.I.S. integrated, 50 mm, 0°, 35 mm, aluminium |
Saddle |
Proxim W350
|
Seatpost | Post Moderne dropper post PM-214, 34.9 mm |
Weight |
26.6kg inc battery |
Carry Capacity | 150kg inc rider |
Geometry | See Focus website |
Lights | No - mounts provided |
---|---|
Lock | No |
Carrier Rack | No - mounts provided |
Mudguards |
No - mounts provided
|
Kickstand | No |
