Tern GSD S10 LR EBike
Tern GSD S10 LR EBike
The Tern GSD S10 cargo ebike is renowned as a strong, safe family carrier and the "LR" version is the base model with Shimano Deore 10-sp gearing and 400Wh battery. With a 200kg weight rating and a 20" wheel base it is compact and easy to manage and with the strong Bosch Cargo Line motor carrying heavy loads is a breeze. Foldable handlebars and vertical parking make it practical for apartment living too. With Tern's excellent accessory range you can configure it so it not only fits in with your life, it will improve it.
- Drive System: Gen 4 Bosch Cargo Line
- Motor: 250W mid-drive, 85Nm of torque
- Battery: Bosch Lithium-ion 400Wh (powerpack)
- Comfort: Front suspension, adjustable handlebars, balloon tires, ergonomic seat and grips
- Accessories: Lights, lock, mudguards, heavy duty rear carrier rack, heavy duty kickstand
- Brand: Tern
Incredibly useful and economical family carrier. The Tern GSD is renowned as a strong, safe family carrier and is famous for its ability to easily carry two children onboard. The "LR" version is the most economical version with the 400Wh battery.
With a 200kg weight rating and a 20" wheel base it is compact and easy to manage. The strong Bosch Cargo Line motorwith its 85Nm torque and 400% assist in turbo helps you carry heavy loads up any hill with ease. The "LR" comes with a 400Wh battery and is built ready to add a second battery for 900Wh capacity if you need it.
The GSD frame has been updated to be slightly longer and much stiffer making it balanced to ride and very stable when loaded. Handlebars and stem can be easily adjusted to suit different rider heights and Tern estimate it suits riders from 150cm to 195cm in height. It also has a lower stepthrough style that makes it easy to get on and off and, with the clever Atlas kickstand, it very stable with a clever remote lever that unlocks it when you roll forward.
The Tern GSD S10 rolls along on strong purpose-made wheels that have balloon puncture resistant tires which add extra traction and extra comfort. A range of 10 gears is provided by the hardwearing Shimano Deore shifting system and you can rely on the German-made Magura hydraulic disc brakes to pull you up quickly and smoothly when required.
Tern is renowned for its excellent range of practical accessories for the GSD. This year the range has increased with more options for carrying adults such as the Captains Chair and more options for carrying extra luggage with children.
An incredibly useful bike that will enhance daily life through its ability to provide safe and fun transport. If you prefer the larger battery and "LX' package see the Tern GSD S10 LX. Also available by preorder is the belt drive versions with with Rohloff E-14 or Enviolo gearing.
|System||Bosch Cargo Line CX Gen 4|
|Motor||Bosch 250W mid-drive, 85Nm|
Bosch Powerpack 400WhExtra 500Wh battery possible
|Frame||Tern GSD, 6061-AL, patented MultiTruss design|
|Sizes||One size, suits 150cm-195cm
|Colours||Schoolbus Yellow, Beetle Blue|
||Suntour custom for Tern, 1.5" tapered Chromoly steerer, 32 mm stanchions, Thru-axle, 70 mm|
|Front Tire||Schwalbe Big Ben Plus, 55-406, Green Guard puncture protection, Reflex|
|Rear Tire||Schwalbe Super Moto-X, 62-406, Green Guard puncture protection, Reflex|
|Rims||Tern Atlas, ultra wide 36 mm, dual reinforced joint|
|Shifting System||Shimano Deore, 1 x 10 spd|
|Cassette||Shimano 11-36T, 10 spd|
|Chain||10 spd, DHT for eBike, GST corrosion resistant coating|
|Brakes||Magura MT5, 4-piston hydraulic disc, 180 mm rotor, Sport pads|
Tern Sweep, 6061-AL, Tern Andros adapted
|Stem||Tern Andros, adjustable, forged construction, patented technology|
Tern GSD by Velo, with rear handle
Tern Telescope, 34.9/30.9 mm, 2014-AL
|Carry Capacity||EFBE Tri-Test approved: 200 kg|
|Folding Size||176 x 40.5 x 83 cm (69.3" x 15.9" x 32.7")|
Front: Ignis Headlight, Ultra wide 700 lumens, Hi/Lo BeamRear: RearStop Brake Light, Always on brake light
|Lock||ABUS, keyed-alike with Bosch battery|
|Carrier Rack||Frame integrated, heavy duty design|
Integrated Wheel Guard, AL6061, w/ Side Skirt
Atlas Lockstand, w/ remote unlock, patented technology
|Accessories||An excellent selection to customise your bike
See Tern website for details
