| Rider Height (cm) | Bike Frame (cm) | Bike Size |
|---|---|---|
| 155 - 165 | 40.5 | XS |
| 166 - 173 | 43.8 | S |
| 174 - 179 | 47.1 | M |
| 180 - 185 | 50.4 | L |
| 186 - 191 | 53.7 | XL |
| 192 - 207 | 57 | XXL |
1
Available
0% FINANCE AVAILABLE
Orbea Denna H50 Gravel E-Bike
Full Specification
Orbea Denna H50 Gravel E-Bike
Bike Overview
Tough, light, versatile, top value. The Orbea Denna ebike is a cutting-edge gravel e-bike and the Denna H50 is a tough, top value alloy model. Light in weight it offers the incredible handling and comfortable geometry from the Denna platform with simpler controls and gearing. With the help of the strong Shimano EP600 motor the Denna is built for adventure and enjoyable riding.
Powerful, natural assistance with long-range battery. The Denna is equipped with the Shimano EP600 motor which provides 85Nm of smooth, natural-feeling power. The high density 420Wh battery is lightweight and offers up to 3,000m climbing plus there is an optional 210Wh range extender if you plan extra-long rides.
Comfort for the long haul. The Denna’s frame and carbon fork are designed with flex zones to absorb road chatter while maintaining efficiency. The gravel-optimized geometry, wider tire clearance, balanced weight distribution and carefully selected components ensure a stable, comfortable ride on any surface.
Contact us to custom order or order incoming stock. If you prefer a lighter carbon version see the Denna M30.
EBike Technology
| System | Shimano |
|---|---|
| Motor |
Shimano EP600 |
| Battery |
Orbea Internal 420Wh Opt: Range Extender 210Wh |
| Display |
n.a |
| Remote |
EN600-L |
| Charger |
Orbea 2.Generation eBike Smart charger 42V/2-4A |
Bike Specification
| Frame |
Orbea Denna, Thru Axle 12mm x 142mm rear, thread M12xP1, internal cable routing |
|---|---|
| Sizes | XS:40.5; S:43.8; M:47.1; L:50.4; XL:53.7 |
| Colours | Ivory White, Blue Stone, Magnetic Bronze |
| Fork |
Orbea Denna OMR ICR, full carbon, 1-1/8" - 1,5" tapered head tube compatible, Thru axle 12x100mm, thread M12xP1 |
| Rear Derailleur |
Shimano Cues U6000 GS Shadow |
| Shifters |
Shimano U6030 |
| Cassette |
Shimano CS-LG300 11-48t 10-Speed |
| Crank |
Shimano Steps EM600 |
| Chain |
Shimano LG500 |
| Chainring |
Alloy EP8 42t |
| Chain Guide | Orbea eBike chainguide |
| Handlebar |
OC Gravel GR31, Reach 70, Drop 110 |
| Handlebar Tape | Orbea Anti-Slippery/Shock Proof |
| Stem |
OC Road Performance RP23, -5º Opt: OC Road Performance RP23, +15º |
| Brakes |
Shimano RS405 Hydraulic Disc |
| Seatpost |
SP 0.2 Carbon, 27.2mm, Setback 0 |
| Saddle |
Selle San Marco Shortfit 2.0 Start Up Off Road |
| Wheels |
Alloy, Tubeless, 700c, 21c |
| Tyres |
Vittoria Terreno Dry Gravel G2.0 TLR 700x45c |
| Pedals | n.a |
| Weight |
Approx 15.5kg tbc |
Fitted Accessories
| Lights | No |
|---|---|
| Lock | No |
| Carrier Rack | No |
| Mudguards | Opt: Front/rear Apollo Orbit Mudguards 55mm NEG |
| Kickstand | No |
Tough, light, versatile, top value. The Orbea Denna ebike is a cutting-edge gravel e-bike and the Denna H50 is a tough, top value alloy model. Light in weight it offers the incredible handling and comfortable geometry from the Denna platform with simpler controls and gearing. With the help of the strong Shimano EP600 motor the Denna is built for adventure and enjoyable riding.
Powerful, natural assistance with long-range battery. The Denna is equipped with the Shimano EP600 motor which provides 85Nm of smooth, natural-feeling power. The high density 420Wh battery is lightweight and offers up to 3,000m climbing plus there is an optional 210Wh range extender if you plan extra-long rides.
Comfort for the long haul. The Denna’s frame and carbon fork are designed with flex zones to absorb road chatter while maintaining efficiency. The gravel-optimized geometry, wider tire clearance, balanced weight distribution and carefully selected components ensure a stable, comfortable ride on any surface.
Contact us to custom order or order incoming stock. If you prefer a lighter carbon version see the Denna M30.
| System | Shimano |
|---|---|
| Motor |
Shimano EP600 |
| Battery |
Orbea Internal 420Wh Opt: Range Extender 210Wh |
| Display |
n.a |
| Remote |
EN600-L |
| Charger |
Orbea 2.Generation eBike Smart charger 42V/2-4A |
| Frame |
Orbea Denna, Thru Axle 12mm x 142mm rear, thread M12xP1, internal cable routing |
|---|---|
| Sizes | XS:40.5; S:43.8; M:47.1; L:50.4; XL:53.7 |
| Colours | Ivory White, Blue Stone, Magnetic Bronze |
| Fork |
Orbea Denna OMR ICR, full carbon, 1-1/8" - 1,5" tapered head tube compatible, Thru axle 12x100mm, thread M12xP1 |
| Rear Derailleur |
Shimano Cues U6000 GS Shadow |
| Shifters |
Shimano U6030 |
| Cassette |
Shimano CS-LG300 11-48t 10-Speed |
| Crank |
Shimano Steps EM600 |
| Chain |
Shimano LG500 |
| Chainring |
Alloy EP8 42t |
| Chain Guide | Orbea eBike chainguide |
| Handlebar |
OC Gravel GR31, Reach 70, Drop 110 |
| Handlebar Tape | Orbea Anti-Slippery/Shock Proof |
| Stem |
OC Road Performance RP23, -5º Opt: OC Road Performance RP23, +15º |
| Brakes |
Shimano RS405 Hydraulic Disc |
| Seatpost |
SP 0.2 Carbon, 27.2mm, Setback 0 |
| Saddle |
Selle San Marco Shortfit 2.0 Start Up Off Road |
| Wheels |
Alloy, Tubeless, 700c, 21c |
| Tyres |
Vittoria Terreno Dry Gravel G2.0 TLR 700x45c |
| Pedals | n.a |
| Weight |
Approx 15.5kg tbc |
| Lights | No |
|---|---|
| Lock | No |
| Carrier Rack | No |
| Mudguards | Opt: Front/rear Apollo Orbit Mudguards 55mm NEG |
| Kickstand | No |
N/A
N/A
1
Available
0% FINANCE AVAILABLE
Orbea Denna H50 Gravel E-Bike
Regular price
$7,799
$7,799
Sale price
Regular price
Unit price
per
Configure Your Bike
Size Guide
Ask me anything about this bike
Call 07 2102 9775 or Submit Request
Our Quick Review
"A tough, top value alloy gravel ebike. Light in weight, full power it offers the incredible handling and comfortable geometry from the Denna platform with simpler controls and gearing"
